Glass Fiber Reinforced TPU
PECOAT® Glass Fiber Reinforced TPU
A certain proportion of glass fiber is added to enhance the physical and chemical properties of TPU. This makes the product high in strength, wear-resistant, flexible, low in water absorption, and high in elasticity.
Product Features
- Good insulation
- Strong heat resistance
- Good corrosion resistance
- High mechanical strength
Use
The product is widely used in special applications such as electronic plugs, automotive parts, mechanical parts, ships, aerospace, and electronic housings.
| Items | Unit | Typical Value | ||
|---|---|---|---|---|
| Hardness | Shore-A/D | 65D | 75D | 85D |
| Specific Gravity | g/cm3 | 1.32 | 1.38 | 1.45 |
| Tensile strength | MPa | 78 | 85 | 96 |
| Elongation at break | % | 130 | 92 | 65 |
| Tear strength | KN/mm | 142 | 156 | 180 |
| Suggested melting temperature | 160-220℃ | |||
| Drying time | 3H-4H | |||
| Drying temperature | 90-100℃ |
